Linkage Sprayers
Linkage Sprayer ARES HIGH PRESSURE
| Standard equipment | 200 L | 400 L | 600 L | 800 L | 1000 L | 1200 L | 1500 L | 2000 L |
|---|---|---|---|---|---|---|---|---|
| Frame | Reinforced steel | Reinforced steel | Reinforced steel | Reinforced steel | Reinforced steel | Reinforced steel | Reinforced steel | Reinforced steel |
| Cover | Anticorrosion painting | Anticorrosion painting | Anticorrosion painting | Anticorrosion painting | Anticorrosion painting | Anticorrosion painting | Anticorrosion painting | Anticorrosion painting |
| Tank | Polyethylene | Polyethylene | Polyethylene | Polyethylene | Polyethylene | Polyethylene | Polyethylene | Polyethylene |
| Hand whasing tank | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Pump (high pressure) | Diaphragm/piston | Diaphragm/piston | Diaphragm/piston | Diaphragm/piston | Diaphragm/piston | Diaphragm/piston | Diaphragm/piston | Diaphragm/piston |
| Level gauble | Dry visible | Dry visible | Dry visible | Dry visible | Dry visible | Dry visible | Dry visible | Dry visible |
| Tank opening filter | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Suction filter with safety valve | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Hydraulic stirrer | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Pressure regulator | Manual | Manual | Manual | Manual | Manual | Manual | Manual | Manual |
| Step for access of tank opepining | No | No | No | Yes | Yes | Yes | Yes | Yes |
| PTO shaft | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| 2 spray guns | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Anti-pollution hydro-injector | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| 200 L | 400 L | 600 L | 800 L | 1000 L | 1200 L | 1500 L | |
|---|---|---|---|---|---|---|---|
| Length (mm) | 600 | 935 | 910 | 910 | 1050 | 1040 | 1240 |
| Width (mm) | 765 | 1060 | 1400 | 1410 | 1500 | 1500 | 1785 |
| Height (mm) | 120 | 1200 | 1370 | 1560 | 1580 | 1600 | 1830 |
| Weight (kg) | 80 | 120 | 180 | 200 | 250 | 270 | 300 |
| Description |
|---|
| Hose reel 50 m |
| Hose reel 100 m |
| Product mix tank |
| Step for access of tank opepining kit |
| Manual control remote |
