| Frame | Steel with reinforcement bars | Steel with reinforcement bars |
| Cover | Anticorrosion painting | Anticorrosion painting |
| Tank | Polyethylene | Polyethylene |
| Protection | Lateral and front arch of defense | Lateral and front arch of defense |
| Level gauge | Yes | Yes |
| Suction filter | 2" With valve of automatic closing | 2" With valve of automatic closing |
| Cartridge inox. | 16 mesh | 16 mesh |
| Model with pump | | |
| Self-suction | 2" | 2" |
| Maximum flow rate | 700 lpm* | 700 lpm* |
| Gaskets | EPDM** | EPDM** |
| Suction | 5-10m | 5-10m |
| Engine | Hydraulic low-energy | Hydraulic low-energy |
| Hydraulic requirement & max. Pressre | 30 l/150 bar | 30 l/150 bar |
| * The flow changes according to pressure in side of drive (average value 500 lpm) | | |
| ** Vitón's gaskets (recommended for acids), to consult | | |
| *** Electric pump of 12v máx. flow 40 lpm. | | |
